High Precision manual smt stencil printer




PCB Printer

Brief Introduction:

PCB Printer. is a high precision manual stencil solder printer for PCB board.

It is also  small and easy to operate,affordable,which is also suitable for prototype and small scale electronics factory.

Supports frameless stencil, more convenient to printing for prototyping.


Model FP2636(Frameless Stencil)
Max PCB Size/PCB 280*380mm
Min PCB Size/PCB 10*5mm
Screen Stencil Size 260*360mm
Printing Speed Labor control
PCB Thickness 0-20mm
Platform height 190mm
Repeatability ±0.01mm
Max Rotation Angle ±15 Degree
Positioning Mode Outside/Reference Hole
Fine Adjustment Range X/Y/Z Axis(All ±15mm)
Positioning Pin Size 1mm/1.5mm/2.0mm/2.5mm/3mm
Packing Size 660×470×245mm
N.W. 12KG
G.W. 14KG




1.T screw rod regulating handle,ensure adjustment accuracy and levelness of PCB fixed plane,minimum lead pitch achieved 1mm.

2.Adjustable rubber footing,ensure the flatness while operating.

3.Letter mark for each regulating handle,better and easier to operate.

4.Rulers of stencil fixed frame for reference lines,ensure the levelness between stencil and PCB.

5.Straight damping shaft,ensure the stencil fixed frame can be fastened at random angles,to improve convenience while operating.

6.L supports and pins to fix PCB,applicable for multiple types PCBs’fixation and printing,more flexible and convenient.

7.The mechanical fixation frame for quick installation and replacement of frameless stencils,ensure high-efficiency but low-cost.

8.Support for single sided as well as double sided PCB.
