Bitcoin miner L3+


Bitmain Antminer L3+ – Litecoin 504 MH/S

Antminer L3+ (504MH/s) ASIC. Antminer L3+ is a Scrypt mining equipment sold by BitMain. It is able to mine Litecoin (LTC) with a maximum hashrate of 504,000,000H for a power consumption of 800W.

Manufacturer Bitmain
Model Antminer L3+ (504Mh)
Release June 2017
Size 188 x 130 x 352mm
Weight 4400g
Chip boards 4
Chip name BM1485
Chip count 288
Noise level 70db
Fan(s) 2
Power 800W
Wires 9 * 6pins
Voltage 11.6 ~ 13.0V
Interface Ethernet
Temperature 0 – 40 °C
Humidity 5 – 95 %

Category: Tags: Bitcoin miner L3+, Bitcoin miner L3+ for sale near me, how to use Bitcoin miner L3+, where to buy Bitcoin miner L3+, where to buy bitcoin mining machines


Antminer L3+

Antminer L3+ employs 288  chips to deliver more hashrate and also efficiency than any previous Litecoin miner on the market.

The Antminer L3+ follows a form factor similar to that of the hugely popular Antminer S9 and is nearly the same size.

Whether in a home or in a mining farm with several other L3+ miners, the Antminer L3+’s small footprint fits well in all locations.

The L3+ utilizes a combination of conduction and convection cooling to make the world’s most powerful Litecoin miner.

Performs at its best while creating no more heat than the latest terahash Bitcoin miner.

Specifications :

Hash Rate: 504MH/s. A variation of +/- 5% is expected.

Power Consumption: 800W +10% (at the wall, with Bitmain’s APW3 PSU, 93% efficiency, 25°C ambient temperature)

Power Efficiency: 1.6J/MH +10% (at the wall, with Bitmain’s APW3 PSU, 93% efficiency, 25°C ambient temperature)

DC Voltage Input: 11.60 ~ 13.00V

Chip Type: BM1485 ASIC chip

Chip quantity per unit: 288 chips on four hashing boards, 72 chips on one hashing board

Dimensions: 352mm (l) x 130mm (w) x 187.5mm (h)

Operating temperature: 0°C – 40°C

Network connection: Ethernet
